מכשור מעבדה | מנדפים
מצלמת עינית למיקרוסקופ ברזולוציה 21MPa
מודל:מצלמת עינית למיקרוסקופ ברזולוציה 21MPaיצרן:AmScopeמק"ט:MU1403 21MPaמצב:חדששנת ייצור:2024
מצלמת עינית למיקרוסקופ ברזולוציה 21MPa
מצלמת עינית למיקרוסקופ ברזולוציה 21MPa
USB Live Video Microscope Digital Camera
דגם: MU1403 21MPa
תוצרת: AmScope
Camera Specifications:
Senor: Aptina MT9F002 CMOS (Color)
Sensor Size: 1/2.3" (6.138mm(H) x 4.603mm(V), diagonal 7.672mm)
Resolution: 4096 x 3288 (approx. 14,000,000 pixels)
Reduction Lens: 0.5X
Pixel Size: 1.4µm x 1.4µm
G Sensitivity: 0.724v / lux-sec (550nm)
Frame Rate: 54fps @1024x822, 21fps @2048x1644, 6.2fps @4096x3286
Exposure: 0.4~2000ms, ROI Auto & Manual
Scan Mode: Progressive
Dynamic Range: 65.3dB
A/D Converter: 12-bit Parallel, 8-bit R.G.B to computer
SN Ratio: 35.5dB
Spectral Range: 380-650nm (with IR-filter)
Binning: 1x1, 2x2, 4x4
White balance: ROI White Balance/ Manual Temp-Tint Adjustment
Color Rendering Technique: Ultra Fine Color Engine
Capture/Control API: Native C/C++, C#, DirectShow, Twain, LabVIEW
Recording System: Still Picture and Movie
Cooling System: Natural
Operating Temperature: -10°C~50°C
Storage Temperature: -20°C~60°C
Operating Humidity: 30~80%RH
Storage Humidity: 10~60%RH
Power Supply: DC 5V over USB3.0 Port
Software Features:
Operating System: Windows XP/Vista/7/8/10 (32 & 64 bit) and Linux
Computer Requirement: CPU equals to Intel Core2 2.8GHz or higher, Memory:
Advanced software for Windows:
offers to stitching, EDF, video recording and measurement functions
conducts measurements for lengths, angles, arcs, areas and etc.
saves still images in BMP, TIFF, JPG, PICT, PTL or other formats
edit and process microscopy images in a manner similar to Photoshop
live video and still image capture can be set in different resolutions simultaneously
More features: add layers, watermarks, mosaics, tiles; adjust color balance, exposure, saturation, contrast, orientation; change resolution, histogram, granulation, diffusion; transform images via detection, digital image warping; conducts measurements for single, parallel or perpendicular lines and rectangular, elliptical and irregular areas; adds notes, measurements, text, arrows, labels, and etc. using customizable text with different sizes and colors; conducts measurements in microns, millimeters, centimeters, inches, feet, and etc. under any magnification powers with desired tolerances.
USB Live Video Microscope Digital Camera
דגם: MU1403 21MPa
תוצרת: AmScope
Camera Specifications:
Senor: Aptina MT9F002 CMOS (Color)
Sensor Size: 1/2.3" (6.138mm(H) x 4.603mm(V), diagonal 7.672mm)
Resolution: 4096 x 3288 (approx. 14,000,000 pixels)
Reduction Lens: 0.5X
Pixel Size: 1.4µm x 1.4µm
G Sensitivity: 0.724v / lux-sec (550nm)
Frame Rate: 54fps @1024x822, 21fps @2048x1644, 6.2fps @4096x3286
Exposure: 0.4~2000ms, ROI Auto & Manual
Scan Mode: Progressive
Dynamic Range: 65.3dB
A/D Converter: 12-bit Parallel, 8-bit R.G.B to computer
SN Ratio: 35.5dB
Spectral Range: 380-650nm (with IR-filter)
Binning: 1x1, 2x2, 4x4
White balance: ROI White Balance/ Manual Temp-Tint Adjustment
Color Rendering Technique: Ultra Fine Color Engine
Capture/Control API: Native C/C++, C#, DirectShow, Twain, LabVIEW
Recording System: Still Picture and Movie
Cooling System: Natural
Operating Temperature: -10°C~50°C
Storage Temperature: -20°C~60°C
Operating Humidity: 30~80%RH
Storage Humidity: 10~60%RH
Power Supply: DC 5V over USB3.0 Port
Software Features:
Operating System: Windows XP/Vista/7/8/10 (32 & 64 bit) and Linux
Computer Requirement: CPU equals to Intel Core2 2.8GHz or higher, Memory:
Advanced software for Windows:
offers to stitching, EDF, video recording and measurement functions
conducts measurements for lengths, angles, arcs, areas and etc.
saves still images in BMP, TIFF, JPG, PICT, PTL or other formats
edit and process microscopy images in a manner similar to Photoshop
live video and still image capture can be set in different resolutions simultaneously
More features: add layers, watermarks, mosaics, tiles; adjust color balance, exposure, saturation, contrast, orientation; change resolution, histogram, granulation, diffusion; transform images via detection, digital image warping; conducts measurements for single, parallel or perpendicular lines and rectangular, elliptical and irregular areas; adds notes, measurements, text, arrows, labels, and etc. using customizable text with different sizes and colors; conducts measurements in microns, millimeters, centimeters, inches, feet, and etc. under any magnification powers with desired tolerances.
מצלמת עינית למיקרוסקופ ברזולוציה 21MPa
USB Live Video Microscope Digital Camera
דגם: MU1403 21MPa
תוצרת: AmScope
Camera Specifications:
Senor: Aptina MT9F002 CMOS (Color)
Sensor Size: 1/2.3" (6.138mm(H) x 4.603mm(V), diagonal 7.672mm)
Resolution: 4096 x 3288 (approx. 14,000,000 pixels)
Reduction Lens: 0.5X
Pixel Size: 1.4µm x 1.4µm
G Sensitivity: 0.724v / lux-sec (550nm)
Frame Rate: 54fps @1024x822, 21fps @2048x1644, 6.2fps @4096x3286
Exposure: 0.4~2000ms, ROI Auto & Manual
Scan Mode: Progressive
Dynamic Range: 65.3dB
A/D Converter: 12-bit Parallel, 8-bit R.G.B to computer
SN Ratio: 35.5dB
Spectral Range: 380-650nm (with IR-filter)
Binning: 1x1, 2x2, 4x4
White balance: ROI White Balance/ Manual Temp-Tint Adjustment
Color Rendering Technique: Ultra Fine Color Engine
Capture/Control API: Native C/C++, C#, DirectShow, Twain, LabVIEW
Recording System: Still Picture and Movie
Cooling System: Natural
Operating Temperature: -10°C~50°C
Storage Temperature: -20°C~60°C
Operating Humidity: 30~80%RH
Storage Humidity: 10~60%RH
Power Supply: DC 5V over USB3.0 Port
Software Features:
Operating System: Windows XP/Vista/7/8/10 (32 & 64 bit) and Linux
Computer Requirement: CPU equals to Intel Core2 2.8GHz or higher, Memory
:Advanced software for Windows:
offers to stitching, EDF, video recording and measurement functions
conducts measurements for lengths, angles, arcs, areas and etc
saves still images in BMP, TIFF, JPG, PICT, PTL or other formats
edit and process microscopy images in a manner similar to Photoshop
live video and still image capture can be set in different resolutions simultaneously
More features: add layers, watermarks, mosaics, tiles; adjust color balance, exposure, saturation, contrast, orientation; change resolution, histogram, granulation, diffusion; transform images via detection, digital image warping; conducts measurements for single, parallel or perpendicular lines and rectangular, elliptical and irregular areas; adds notes, measurements, text, arrows, labels, and etc. using customizable text with different sizes and colors; conducts measurements in microns, millimeters, centimeters, inches, feet, and etc. under any magnification powers with desired tolerances.
USB Live Video Microscope Digital Camera
דגם: MU1403 21MPa
תוצרת: AmScope
Camera Specifications:
Senor: Aptina MT9F002 CMOS (Color)
Sensor Size: 1/2.3" (6.138mm(H) x 4.603mm(V), diagonal 7.672mm)
Resolution: 4096 x 3288 (approx. 14,000,000 pixels)
Reduction Lens: 0.5X
Pixel Size: 1.4µm x 1.4µm
G Sensitivity: 0.724v / lux-sec (550nm)
Frame Rate: 54fps @1024x822, 21fps @2048x1644, 6.2fps @4096x3286
Exposure: 0.4~2000ms, ROI Auto & Manual
Scan Mode: Progressive
Dynamic Range: 65.3dB
A/D Converter: 12-bit Parallel, 8-bit R.G.B to computer
SN Ratio: 35.5dB
Spectral Range: 380-650nm (with IR-filter)
Binning: 1x1, 2x2, 4x4
White balance: ROI White Balance/ Manual Temp-Tint Adjustment
Color Rendering Technique: Ultra Fine Color Engine
Capture/Control API: Native C/C++, C#, DirectShow, Twain, LabVIEW
Recording System: Still Picture and Movie
Cooling System: Natural
Operating Temperature: -10°C~50°C
Storage Temperature: -20°C~60°C
Operating Humidity: 30~80%RH
Storage Humidity: 10~60%RH
Power Supply: DC 5V over USB3.0 Port
Software Features:
Operating System: Windows XP/Vista/7/8/10 (32 & 64 bit) and Linux
Computer Requirement: CPU equals to Intel Core2 2.8GHz or higher, Memory
:Advanced software for Windows:
offers to stitching, EDF, video recording and measurement functions
conducts measurements for lengths, angles, arcs, areas and etc
saves still images in BMP, TIFF, JPG, PICT, PTL or other formats
edit and process microscopy images in a manner similar to Photoshop
live video and still image capture can be set in different resolutions simultaneously
More features: add layers, watermarks, mosaics, tiles; adjust color balance, exposure, saturation, contrast, orientation; change resolution, histogram, granulation, diffusion; transform images via detection, digital image warping; conducts measurements for single, parallel or perpendicular lines and rectangular, elliptical and irregular areas; adds notes, measurements, text, arrows, labels, and etc. using customizable text with different sizes and colors; conducts measurements in microns, millimeters, centimeters, inches, feet, and etc. under any magnification powers with desired tolerances.
